Centrifugal Fire Smoke Exhaust Fan for FM200 Fire System - High Pressure Stainless Steel

Name: Centrifugal Fire Smoke Exhaust Fan for FM200 Fire System High Pressure Stainless Steel
Brand: XINGJIN
Price: 1 USD

China Centrifugal Fire Smoke Exhaust Fan for FM200 Fire System - High Pressure Stainless Steel wholesale

Brand Name : XINGJIN

Model Number : HTFC

Certification : CCC,CAC,ROHS

Place of Origin : Guangzhou,China

MOQ : 5 set

Price : Pricing based on quantity

Payment Terms : T/T, L/C

Supply Ability : 30000set/month

Delivery Time : According to product quantity

Packaging Details : Wooden Box Or Plywood Outer Box With Bubble Bag Or Paper

Fan Type : Axial flow fire smoke exhaust fan

Customized support : OEM, ODM

Mounting type : Duct Fan

Blade material : Aluminum

Warranty : 2YEAR

Maximum operating temperature : 280℃

Installation : Vertical, Horizontal, Hanging

Speed : 450-1200r/min

Power : 0.55-45KW

Color : Blue; White;Customized colors

Model Specifications : HTFC-9;HTFC-10;HTFC-12...

Contact Now

HTFC-I centrifugal fire smoke exhaust fan

Introduction:
The HTFC series dual-purpose, low-noise centrifugal fume cabinet for fire smoke exhaust (ventilation) is designed and manufactured by our company by absorbing advanced domestic and international technologies and integrating our years of meticulous fume cabinet research to optimize fan performance, including pressure and air volume. This latest product offers multiple functions for both ventilation and fire smoke exhaust. It has passed inspection by the National Fire Equipment Quality Testing Center and complies with the GA211-1999 Fire Smoke Exhaust Fan Test Method and JB/TI0218-2001 Fire Smoke Exhaust Fan Technical Requirements. It has also received China's mandatory 3C certification. It has demonstrated normal operation at a medium temperature of 280°C for more than 30 minutes, complying with GB50045 (Code for Fire Protection Design of High-Rise Civil Buildings).

Applicable scenarios:
This fan is suitable for use in venues requiring ventilation and fire smoke exhaust, such as stadiums, exhibition centers, hotels, office buildings, theaters, auditoriums, hospitals, shopping malls, high-rise residential buildings, basements (parking lots), factories and mines, and indoor spaces in large buildings.

Model parameters:

Model (NO)	Power (KW)	Speed (r/min)	Flow (m/h)	Pressure (Pa)	Noise dB(A)
HTFC-9	0.55	900	2581-3703	195-174	≤58
	0.75	1000	2540-4233	255-273	≤62
	1.1	1100	2876-4753	306-316	≤63
	1.5	1200	3126-5049	367-372	≤66
HTFC-10	0.55	800	2484-3703	199-212	≤62
	0.75	900	2718-4113	255-270	≤64
	1.1	1000	3040-4692	300-332	≤66
	1.5	1100	3437-5 528	384-393	≤68
	2.2	1200	3582-5877	431-454	≤70
HTFC-12	0.75	700	3599-5710	243-249	≤59
	1.1	800	4102-6355	308-318	≤61
	1.5	900	4877-7176	386-394	≤65
	2.2	1000	5123-7939	473-479	≤67
	3	1100	5674-8818	571-578	≤69
HTFC-15	1.5	700	6179-9698	352-364	≤61
	2.2	800	6953-11164	457-479	≤64
	3	850	7293-11810	510-532	≤65
	4	900	7645-12337	569-595	≤67
	5.5	1000	8466-14156	701-734	≤70
HTFC-18	2.2	600	8288-12595	352-357	≤60
	3	700	9170-15329	463-474	≤62
	4	750	10319-16325	532-549	≤64
	5.5	800	11176-17557	601-617	≤65
	7.5	900	12208-19434	753-768	≤74
HTFC-20	3	550	10660-16150	329-378	≤60
	4	600	11739-17557	390-449	≤62
	5.5	650	12607-19084	457-522	≤64
	7.5	700	13533-20454	529-606	≤66
	11	800	15399-24114	680-778	≤69
HTFC-22	4	550	13311-20255	362-402	≤60
	5.5	600	14964-22894	405-476	≤62
	7.5	650	6009-23774	482-552	≤65
	11	700	17205-25756	563-645	≤66
	15	800	20032-29932	733-827	≤69
HTFC-25	5.5	500	20055-29932	381-413	≤67
	7.5	550	21968-32736	456-495	≤67
	11	600	23960-35270	531-589	≤70
	15	650	26084-38823	632-682	≤73
	18.5	700	28161-42190	713-785
HTFC-28	7.5	450	25369-35270	390-413	≤65
	11	500	27716-39879	472-509	≤68
	15	550	31199-43481	562-606	≤70
	18.5	600	33604-47610	665-726	≤72
	22	650	36607-51457	782-854	≤75
HTEC-30	11	400	28172-41700	368-390	≤76
	15	450	31551-45838	458-492	≤79
	18.5	500	35903-51762	568-601	≤81
	22	550	36665-56360	675-720	≤84
	30	600	40900-63315	805-854	≤86
HTFC-33	15	400	40783-61087	425 -462
	18.5	450	44923-68852	536-577	≤81
	22	500	49638-76549	657-708	≤83
	30	550	54659-84406	792-852	≤85
	37	600	60641-91866	929-1004	≤88
HTFC-36	18.5	400	45127-69056	436-486
	22	450	64505-77309	553--622	≤83
	30	500	1023-87294	670-742	≤84
	37	550	77707-110827	789-898	≤86
	45	600	111947-120452	940-1073	≤88
